Carbon Offroad - RS9-S 9000lb Short Drum Winch - Winch Only

THIS ITEM IS WINCH ONLY

The Carbon Offroad Scout Pro RS Series winches are built with racing and high-speed winching applications in mind.

With larger modulus gearsets and increased motor horsepower, the RS Series is engineered for rapid line speed and controlled recoveries. This winch-only configuration includes a synthetic rope and rope thimble, while other accessories are supplied separately.

The RS series winches share the same 2023 Version 3 Winch Chassis as our tried and tested 12K winch. Due to the longer 8.0HP motor, you should consult the technical drawing to determine clearance and fitment length on your winch mount. The responsibility of fitment is that of the end user or installer.

The RS9-S 9000lb short drum winch is supplied with 8mm high density pre-stretched premium UHMWPE winch rope, rated at 14,000lb minimum breaking strain, terminated with a heavy-duty rope thimble.

Combatable with Carbon Offroad Air Freespool Clutch Upgrade, specifically designed for use with Carbon Offroad 12K and Scout Pro winches.

Features

• Carbon Winch shortened 2023 V3 winch chassis
• 8.0HP series-wound motor
• 80:1 heavy-duty performance gearbox
• Short drum configuration for high-speed winching
• 8mm synthetic UHMWPE rope with rope thimble fitted
